Lifud DALI to PWM converter

Product descriptionLF-SCD010C is a non-isolated signal converter, transforming the DALI signal to PWM output. It conforms to the DALI protocol IEC 62386-101, 102, 103, 206. Input voltage ranges from 10VDC to 22.5VDC. One converter can control one LED driver. It flexibly fits in many different DALI lighting system designs. Feature- Output PWM dimming signal; compatible withPWM dimmable driver; high performance,high reliability- Dimming range 10%-100% (dim to off)- DALI dimming function; The logarithmicdimming mode and linear dimming mode canbe selected via DALI interface.- IP67 rating; waterproof casing- Warranty: 5 yrs (Please refer to the warranty description.) Application- Plant lighting- Indoor office lighting- Decorative lighting- Commercial lighting- Residential lighting Product informationPWM Range 10%-100% (dim to off) PWM Voltage 10VDC PWM Source Current 5mA (Max.) PWM Tolerance ±5% Frequency 1KHz Temperature Drift ±5% Start-up Time <1S@16VDC, DALI typical voltage Input Voltage 10-22.5VDC Input Current ≤5mA Working Temperature -30℃~ 60℃ Working Humidity 20-90%RH (no condensation) Storage Temperature & Humidity -30℃~ 60℃ (six months under class I environment);10-90%RH (no condensation) Atmospheric Pressure 86KPa~106KPa Certification Conform to CE Electromagnetic Emission Conform to EN55015 IP Rating IP67 RoHS RoHS 2.0 (EU) 2015/863 Warranty 5 years Implementation Standards of DALI IEC 62386-101, 102, 103, 206 Shipping Product can be shipped with these shipping methods. PostNord MyPack Collect 8,00 € Delivery in 1-3 business days. Package will be kept for 7 days at the pickup point. PostNord MyPack Home Finland 19,00 € Door to door service, delivery in 2-6 business days. PostNord Finland Parcel (For companies) 12,00 € Delivery in 1-3 business days. Door to Door service for business addresses. Matkahuolto Lähellä-package 8,50 € Delivery usually in 2-5 business days. The package will be kept for 7 days in the pick up location. Posti Standard Delivery Finland 9,00 € Delivery in 2-5 business days. DSV Parcel service point 8,50 € Delivery in 2-5 business days. Pick Up from Warehouse 0,00 € Pick up from warehouse (Rajakivenkatu 8, 20740 Turku) between 9AM-3PM on weekdays (closed on weekends and on national holidays). Products are ready for pick up in 3 hours.
